fine powder crusher
easy handling fine powder crusher easy handling fine powder crusher ------fine powder crusher is applicable for both dry and wet crushing.fine powder crusher is widely used for medium or fine crushing for medium hard and brittle materials by departme
easy handling fine powder crusher
easy handling fine powder crusher ------ fine powder crusher is applicable for both dry and wet crushing.fine powder crusher is widely used for medium or fine crushing for medium hard and brittle materials by departments of mine, cement, coal,building material, metallurgy, chemical industry, road construction,gas chemical industry and thermal power generation, etc. Coal gangue,coke, slag, limestone, phosphate rock, salt, whiting, gypsum stains,alum, brick and tile, etc. can be crushed by this equipment. The compression strength of the materials shall not exceed 100MPa, while the moisture content shall be lower than 15%.
easy handling fine powder crusher application
easy handling fine powder crusher ----- fine powder crusher can be also used for crushing chips and paper with fiber structure and strong elasticity and ductility, or recycling asbestos fiber by crushing wastes of asbestos cement, etc. Gap between the gratings areadjustable to change grain size of the discharge, so as to meet different requirements of the customers.
Main features of easy handling fine powder crusher
With large feed inlet and high crushing cavity, the equipment is applicable for hard and large materials. There is little rock powder in the products. Since the materials are suspended, the power consumption for crushing is low. The new kind of hammer canprovide great impact. The hammer axle is adjustable, and the hammer hasa long service life. Gap between the gratings are adjustable to changegrain size of the discharge, so as to meet different requirements of the customers.
The chassis is able to turn for convenient maintenance. The square shank bolt is resistant to impact and wear.With compact structure, this is with high rigidity. Hammer crusher is convenient for transportation and installation due to split structure of the equipment. Combining the functions of impact, reaction and blow in one, with little component wearing and prominent comprehensive benefits, the equipment is widely used for artificial sand making.
Working principle:
Impact Hammer Crusher Materials enter crushing chamber from feeding hopper, and are
impacted to wear-resisting toothed plates on inlet by high speed hammers, this is the first crushing process. Crushed materials with almost the same size enter the main crushing chamber for second crushing. Materials from main crushing chamber are impacted between toothed plates and hammers for many times, and discharged from the outlet. Final product size can be controlled by adjusting space between rotor and impact plates
Advantage of impact crusher
- Simple structure, small volume.
- Large feeding inlet and high crushing cavity, adapt to high hardness materials.
- High reduction ratio and crushing efficiency. The discharge material size can be adjustment, the crushing specification is variety.
- No-board connection. Easy maintenance and reliable operation.
- Crushed product with cubical shape.
|
PXJ fine crusher
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
Width of rotor ø×(mm)
|
|
Model *specification
|
800×400
|
800×800
|
1000×1000
|
1200×1200
|
1400×1400
|
1600×1600
|
1800×1800
|
|
Inlet size(mm)
|
400×185
|
550×330
|
1000×350
|
1200×450
|
1500×500
|
1600×550
|
1800×800
|
|
Feeding material size(mm)
|
<120
|
<180
|
<180
|
<180
|
<190
|
<190
|
<190
|
|
Discharging material size(mm)
|
<0.3-5
|
<0.3-5
|
<0.3-5
|
<0.3-5
|
<0.3-5
|
<0.3-5
|
<0.3-5
|
|
Discharging gap width adjustment
|
5-20
|
5-20
|
5-20
|
5-20
|
5-20
|
5-20
|
5-20
|
|
Cement clinker
(T/H)
|
20-30
|
35-45
|
45-55
|
100-110
|
100-150
|
170-210
|
250-270
|
|
limestone(T/H)
|
35-45
|
55-65
|
65-75
|
90-100
|
100-150
|
190-250
|
280-310
|
|
Equipped power(KW)
|
37-45
|
45-55
|
55-75
|
100-132
|
160
|
250
|
315
|
