Laterite nickel ore ball press machine Is different from ordinary pressure ball machine, due to the moisture content is higher, laterite nickel ore is difficult demoulding, so we must carry on the special research on the design, on the one hand, we should start from the geometric shapes, on the other hand, from the aspects of material selection, we should choose wear resistance, high hardness, high density material. Laterite nickel ore ball press machine can making balls according to the requirements of the reduction roasting process, in laterite nickel ore grinding pressure, making different shape and size of nickel ball, after drying into the rotary kiln reduction roasting



Laterite nickel ore pressure ball press machine is with a high pressing force, roll skin wearability and demoulding,which is easy to form balls with high efficiency, convenience and economy for the research and development principles, designed the new ball press machine equipment.

1. Provide a full range of products 520-1200 - mm roller diameter,

2. The mandatory preloading output 11 t/cm line pressure;

3. Special bearing steel wear-resistant roller surface for 6000 hours;

4. Enclosed gear reducer is with low noise and does not leak;

5. Forming ball laboratory to provide professional experiment for forming ball.



model	Working efficiency	Roll diameter	Roll width	power	reducer	End product shape
ZD-0.5	0.5T/H	299	110	18.5KW	ZQ650	user-defined
ZD-1.0	1.0T/H	367	183	37KW	ZQ850	user-defined
ZD-1.5	1.5T/H	387	210	45KW	ZQ850	user-defined
ZD-2.0	2.0T/H	399.5	232	45KW	ZQ850	user-defined
ZD-2.5	2.5T/H	480	196	55KW	ZQ1000	user-defined
ZD-3.0	3.0T/H	522	196	55KW	ZQ1250	user-defined
ZD-5.0	5.0T/H	700	255	75KW	ZQ1450	user-defined
