The mineral powder ball press machine is used to making balls directly from the crushed materials, without adding water. Such as: aluminum, activated carbon, alumina, quick lime,coal, etc. Its purpose is to reduce the dust, the control capacity, return to use, facilitate transportation.





Metallurgical materials briquetting press machine is mainly used for no water portion of the material made of ball pressure. Such as: quick lime powder, magnesium oxide powder, copper fine powder, lead, zinc waste, aluminum vanadium and soil, nonferrous metal powder, refractory material, ceramic material through the high strength high capacity of high ball made of eggs. Widely used on metallurgical, chemical, refractories, etc.



Its unique design with lowest operating cost and very less maintenance for years makes it very successful & different from others.
Unique mechanical design of Whole Body

Highlysophisticated engineering and State of the art manufacturing process results the world class quality and consistency.



This series of Metallurgical materials briquetting press machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball



model	Working efficiency	Roll diameter	Roll width	power	reducer	End product shape
ZD-0.5	0.5T/H	299	110	18.5KW	ZQ650	user-defined
ZD-1.0	1.0T/H	367	183	37KW	ZQ850	user-defined
ZD-1.5	1.5T/H	387	210	45KW	ZQ850	user-defined
ZD-2.0	2.0T/H	399.5	232	45KW	ZQ850	user-defined
ZD-2.5	2.5T/H	480	196	55KW	ZQ1000	user-defined
ZD-3.0	3.0T/H	522	196	55KW	ZQ1250	user-defined
ZD-5.0	5.0T/H	700	255	75KW	ZQ1450	user-defined
